manual universal milling machine XA7140 bench milling machine

Name: manual universal milling machine XA7140 bench milling machine
Brand: SGSK
SKU: XA7140
Price: 20 USD
Availability: InStock
Rating: 5 (118 reviews)

Large Image : manual universal milling machine XA7140 bench milling machine

Product Details:

Place of Origin:	Shandong, China
Brand Name:	SGSK
Certification:	CE ISO9001
Model Number:	XA7140

Payment & Shipping Terms:

Price:	$20,190.00/Sets 1-9 Sets
Packaging Details:	Machine model:manual universal milling machine XA7140 bench milling machine<br>Package:one machine with one plywood case and steel set below
Supply Ability:	100 Set/Sets per Month

Contact Now

Detailed Product Description

Table Travel (X) (mm):	800 Mm	Number Of Axes:	3
Machining Capacity:	Medium Duty	Table Travel (Y) (mm):	400 Mm
Table Travel (Z) (mm):	500 Mm	Spindle Taper:	ISO50
Range Of Spindle Speed(r.p.m):	18 - 1800 R.p.m	Condition:	New
Table Travel (mm):	1440*400mm	Type:	Universal, Bed-type Milling Machine
Spindle Motor Power(kW):	7.5	Voltage:	220/380/415v
Dimension(LWH):	229018402080mm	Weight (KG):	3860
Warranty:	1 Year	Key Selling Points:	Competitive Price
Applicable Industries:	Manufacturing Plant, Factory	Showroom Location:	Indonesia, Russia
Marketing Type:	Ordinary Product	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Warranty Of Core Components:	1 Year
Core Components:	Motor	Name:	Manual Universal Milling Machine XA7140 Bench Milling Machine
Table Size:	1400*400mm	Spindle Speed Range:	18-1800rpm
Max. Load Working Table:	800KG	Spindle Quill Travel:	105mm
Dis From Spindle To Column Guide Way:	520mm	Spindle Motor Power:	7.5KW
Machine Weight:	3860KG	Overall Dimensions:	2290x1840x2080mm
After-sales Service Provided:	Online Support, Video Technical Support	After Warranty Service:	Video Technical Support, Online Support
Local Service Location:	UAE, Indonesia, Russia	Port:	Qingdao Or Any Port In China

manual universal milling machine XA7140 bench milling machine

The main performance characteristics:
Using MEEHANITE cast iron,
Using rectangular guide machine is Rigid good,
Work table and guide rail through the ultra audio spark quenching.
Milling head can be rotated 30 degrees,
Import frequency conversion and frequency conversion technology to make the spindle more convenient

Details Display

Application:
This machine is a kind of general metal cutting machine tool.
Spindle taper hole of the machine can be directly or through the attachment installed all cylindrical milling cutter, disc cutter,
molding cutter, end milling cutter tool, suitable for processing a variety of small parts of plane, inclined plane, grooves,
holes, and other gear. Is a mechanical manufacturing, mold, equipment, instruments, automobiles, motorcycles and other industries of the ideal processing equipment.

Product main technical parameters:

Specifications	Units	XA7140
Table size	mm	1400x400
Table stroke	mm	800x400
T-type slot numbers / width /space	mm	3-18-100
Max. load working table	kg	800
Distance from spindle axis to column guide way	mm	520
Distance from spindle nose to table surface	mm	150-650
Spindle taper		ISO50
Spindle quill travel	mm	105
Spindle speed range	rpm	18-1800
Spindle motor power	KW	7.5
Overall dimensions	mm	2290x1840x2080
Machine weight	Kg	3860

Recommend Products

Company Profile

FAQ

1. What is your minimum order quantity and warranty?
A: MOQ is one set, and warranty is one year.

2.What CNC system do you use?
A: FANUC, SIEMENS, MISTSUBISHI, LNC,SYNETC,GSK,etc. It depends on your choice.

3.When is the delivery time?
A: Conventional Machines,We will delivery then within 30-45 working days after received your deposit,if some special machines will
be some longer.we will give you the answer accordingly.

4. What is the package of the machines?
A: The machines standard packed by iron pallets with plastic films.

5.How can I choose the most suitable machines ?
A: Please let us know your machining demand or machine size ,we can choose the best model for you , or you can choose the exact model by yourself. You can also send us the products drawing ,we will choose the most suitable machines for you .

6. What is your trade terms?
A : FOB, CFR,CIF or others terms are all acceptable.

8. What is the payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
