Product Details:
Payment & Shipping Terms:
|
| Table Travel (X) (mm): | 1000 | Number Of Axes: | 3 |
|---|---|---|---|
| Machining Capacity: | Light Duty | Table Travel (Y) (mm): | 320 |
| Table Travel (Z) (mm): | 400 | Spindle Taper: | ISO40 |
| Range Of Spindle Speed(r.p.m): | 48 - 1660 R.p.m | Condition: | New |
| Table Travel (mm): | 1000X320X400 | Type: | Universal |
| Spindle Motor Power(kW): | 4 | Voltage: | 220V, 380V, 410V |
| Dimension(L*W*H): | 2550x2050x2050mm | Weight (KG): | 2580 |
| Warranty: | 13 Months | Key Selling Points: | Competitive Price |
| Applicable Industries: | Machinery Repair Shops, Manufacturing Plant | Showroom Location: | Chile, Colombia, Indonesia |
| Marketing Type: | New Product 2020 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Name: | Tool Milling Machine Hobby X6436 Milling Table Price |
| Color: | Customer Request | Table Size: | 1500x360 |
| Spindle Speeds Range: | 48-1660 | Table Travel: | 1000x320x400 |
| T-slots(number *width *pitch ): | 3-18*80 | Motor: | 4 |
| Function: | Metal Milling | Brand: | SGSK |
| Port: | Qingdao Or Any Port In China |
|
Specifications
|
Units
|
X6436
|
|
Table size
|
mm
|
1500x360
|
|
Table travel
|
mm
|
1000/320/400
|
|
T-slot numbers / width /space
|
mm
|
3-18-80
|
|
Spindle taper
|
|
ISO40
|
|
Distance between spindle axis and table surface
|
mm
|
0-400
|
|
Distance between spidle axis and ram surface
|
|
150-550
|
|
Spindle speed range
|
rpm
|
48-1660(V)
40-1300(H) |
|
Range of table feed
|
mm /min
|
X/Y:22-555,Z:electric
|
|
Milling head swivel range
|
°
|
360
|
|
Spindle motor power
|
kw
|
4(H)/4(H)
|
|
Weight
|
kg
|
2580
|
|
Overall dimension
|
mm
|
2550x2050x2050
|
Tel: 0632-5083879
