turret milling machine X6328 milling machinery turret milling

Name: turret milling machine X6328 milling machinery turret milling
Brand: SGSK
SKU: X6328
Price: 5 USD
Availability: InStock
Rating: 4.9 (139 reviews)

Large Image : turret milling machine X6328 milling machinery turret milling

Product Details:

Place of Origin:	China
Brand Name:	SGSK
Model Number:	X6328

Payment & Shipping Terms:

Price:	$5,410.00/Sets 1-4 Sets
Packaging Details:	Name: turret milling machine X6328 milling machinery turret milling<br>Packaging :plywood case
Supply Ability:	200 Set/Sets per Month

Contact Now

Detailed Product Description

Table Travel (X) (mm):	600	Number Of Axes:	3
Machining Capacity:	Medium Duty	Table Travel (Y) (mm):	240
Table Travel (Z) (mm):	360	Spindle Taper:	ISO40
Range Of Spindle Speed(r.p.m):	65 - 4500 R.p.m	Condition:	New
Table Travel (mm):	600240360	Type:	VERTICAL
Spindle Motor Power(kW):	2.2	Voltage:	380v 410v 220v
Dimension(LWH):	155016502250	Weight (KG):	1400
Warranty:	13 Months	Key Selling Points:	Competitive Price
Applicable Industries:	Machinery Repair Shops, Manufacturing Plant	Showroom Location:	Colombia, Indonesia, Mexico, Russia
Marketing Type:	New Product 2020	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Warranty Of Core Components:	1 Year
Core Components:	Bearing, Motor	Name:	Turret Milling Machine X6328 Milling Machinery Turret Milling
Function:	Metal Milling	Color:	Blue
Model:	X6328	Precision:	High Precision
Spindle Speed:	65-4500/80-5440 Rpm	Brand:	SGSK
Spindle:	ISO40	Table Size:	1200*280
Use:	Machining Machine	Port:	Qingdao Or Any Port In China

turret milling machine X6328 milling machinery turret milling

Product Paramenters

Title goes here.

The main performance characteristics: 1. Has the advantages of compact structure, small volume, high flexibility, milling head can rotate left and right 90 degrees, 45 degrees before and after rotation, rocker can not only before and after the expansion, and can make a 360 degree rotation in the horizontal plane, greatly improving the effective working range of machine tools. 2 the body is made of high precision cast iron, which has high precision and long service life. 3 Main shaft is made of chromium molybdenum alloy, and is equipped with precise angular contact bearing, After quenching and tempering treatment and precision grinding, high precision and high precision. Large Spindle speed range, high speed ,Spindle sleeve can be motor fixed range, and equipped with overload protection device. 4. It can be widely used for processing plane, inclined planes with arbitrary angle, keyway milling, grooves, can also turn, reaming, boring, and so on, optional mechanical feed device and a digital display system. Application: Universal radial milling machine is a kind of medium and small general metal cutting machine tools, that can lie milling and can vertical milling. extensive use of performance Spindle taper hole of the machine can be directly or through the attachment installed all cylindrical milling cutter, disc cutter, molding cutter, end milling cutter tool, suitable for processing a variety of small parts of plane, inclined plane, grooves, holes, and other gear. Is a mechanical manufacturing, mold, equipment, instruments, automobiles, motorcycles and other industries of the ideal processing equipment.

Products Description

Details Images

Product main technical specifications:

Specifications	Units	X6328
Table size	mm	1200x280
Table travel	mm	600/240/360
T slot(number-width-pitch)	mm	3-14-63
Spindle taper		ISO40 7:24
Spindle speed range	rpm	(V) 50HZ:65-4500 60HZ:80-5440 (16 steps); (H) 40-1300(12steps
		Optional:(variable)65-4000
Spindle travel	mm	127
Spindle feed range	mm	0.04,0.08,0.15 (3 steps)
Distance between spindle nose and table surface	mm	140-500
Distance between spindle axis and table surface	mm	0-360
Main motor power	kw	2.2(V)3(H)
Head rotation (left - right )	°	±90°
Head rotation (front - rear)	°	±45°
Weight	kg	1400
Overall dimension	mm	1550x1650x2250
