Mill X6032 Small Horizontal Milling Machine For Metal

Name: Mill X6032 Small Horizontal Milling Machine For Metal
Brand: SGSK
SKU: X6032
Price: 7 USD
Availability: InStock
Rating: 4.7 (198 reviews)

Large Image : Mill X6032 Small Horizontal Milling Machine For Metal

Product Details:

Place of Origin:	China
Brand Name:	SGSK
Model Number:	X6032

Payment & Shipping Terms:

Price:	$7,150.00/Sets 1-4 Sets
Packaging Details:	Name:X6032 small horizontal milling machine for metal<br>Packaging :plywood case
Supply Ability:	200 Set/Sets per Month X6032 small horizontal milling machine for metal

Contact Now

Detailed Product Description

Table Travel (X) (mm):	800 Mm	Number Of Axes:	3
Machining Capacity:	Medium Duty	Table Travel (Y) (mm):	300 Mm
Table Travel (Z) (mm):	400 Mm	Spindle Taper:	ISO40
Range Of Spindle Speed(r.p.m):	40 - 1300 R.p.m	Condition:	New
Table Travel (mm):	1500x320mm	Type:	Horizontal
Spindle Motor Power(kW):	3	Voltage:	220V 380V 415V
Dimension(LWH):	2070x1900x1850	Weight (KG):	2050
Warranty:	1 Year	Key Selling Points:	Competitive Price
Applicable Industries:	Machinery Repair Shops, Manufacturing Plant, Factory	Showroom Location:	None
Marketing Type:	Hot Product 2019	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Warranty Of Core Components:	1 Year
Core Components:	Bearing, Motor, Pump, Gear, Engine, Gearbox	Name:	X6032 Small Horizontal Milling Machine For Metal
Model:	X6032 X6032	Table Size:	1500*320mm
Table Stroke:	800/300/400	Dis Between Spindle And Table Surface:	0-400mm
Spindle Speed Range:	58-1800rpm	Spindle Motor Power:	4kw
Overall Dimensions:	207019001850	Machine Weight:	2050
Trade Term:	EXW ,FOB ,CNF ,CIF	Port:	Qingdao Or Any Port In China

X6032 small horizontal milling machine for metal

The main performance characteristics:
1. Using rectangular guide machine is Rigid good,
2. Work table and guide rail through the ultra audio spark quenching.
3. Work bench X. Y all are gear drive automatic feed, Z to the electric lift.

Application:
1. Universal lifting platform milling machine is a kind of general metal cutting machine tool.
2. Spindle taper hole of the machine can be directly or through the attachment installed all cylindrical milling cutter, disc
cutter, molding cutter, end milling cutter tool, suitable for processing a variety of small parts of plane, inclined plane,
grooves, holes, and other gear. Is a mechanical manufacturing, mold, equipment, instruments, automobiles, motorcycles and other industries of the ideal processing equipment.

Products Description

Details Display

Product main technical parameters:

Specifications	Units	X6032
Table size	mm	1500x320
Table travel	mm	800/300/400
T slot(number-width-pitch)	mm	3-16-70
Spindle taper		IS040 7:24
Spindle speed range	rpm	40-1300 (12 steps)
Distance between spindle axis and table surface	mm	0-400
Main motor power	kw	3
Weight	kg	2050

Recommend Products

Company Profile

FAQ

1. What is your minimum order quantity and warranty?
A: MOQ is one set, and warranty is one year.

2.What CNC system do you use?
A: FANUC, SIEMENS, MISTSUBISHI, LNC,SYNETC,GSK,etc. It depends on your choice.

3.When is the delivery time?
A: Conventional Machines,We will delivery then within 30-45 working days after received your deposit,if some special machines will
be some longer.we will give you the answer accordingly.

4. What is the package of the machines?
A: The machines standard packed by iron pallets with plastic films.

5.How can I choose the most suitable machines ?
A: Please let us know your machining demand or machine size ,we can choose the best model for you , or you can choose the exact model by yourself. You can also send us the products drawing ,we will choose the most suitable machines for you .

6. What is your trade terms?
A : FOB, CFR,CIF or others terms are all acceptable.

8. What is the payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
