ZX7045 Drilling Milling Machine Hobby Mill Drill

Name: ZX7045 Drilling Milling Machine Hobby Mill Drill
Brand: SGSK
SKU: ZX7045
Price: 2 USD
Availability: InStock
Rating: 4.7 (174 reviews)

Large Image : ZX7045 Drilling Milling Machine Hobby Mill Drill

Product Details:

Place of Origin:	China
Brand Name:	SGSK
Certification:	CE
Model Number:	ZX7045

Payment & Shipping Terms:

Price:	$2,300.00/Sets 1-9 Sets
Packaging Details:	Name: hobby mill drill ZX7045 Drilling and milling machine mill/drill machines<br>Packaging :plywood case
Supply Ability:	200 Set/Sets per Month

Contact Now

Detailed Product Description

Condition:	New	Type:	Drilling & Milling Machine
Max. Drilling Dia. (mm):	45	Range Of Spindle Speed(r.p.m):	95 - 1600 R.p.m
CNC Or Not:	Normal	Voltage:	220V, 380V, 410V
Dimension(LWH):	9707701160	Power (kW):	1.1
Weight (KG):	318 KG	Warranty:	13 Months
Key Selling Points:	Competitive Price	Showroom Location:	Brazil, Peru, Chile
Applicable Industries:	Manufacturing Plant, Machinery Repair Shops	Marketing Type:	New Product 2020
Machinery Test Report:	Provided	Video Outgoing-inspection:	Provided
Warranty Of Core Components:	1 Year	Core Components:	Motor
Product Name:	Hobby Mill Drill ZX7045 Drilling And Milling Machine Mill/drill	Application:	Metal Processing
Machine Type:	Milling Drilling Machine	Model:	ZX7045
Color:	Blue	Motor Power:	1.1
Max Drilling Capacity:	50	Table Size:	730*210
Spindle Taper:	MT4	Spindle Travel:	120
After Warranty Service:	Video Technical Support, Online Support	Local Service Location:	Brazil, Peru, Chile
Port:	Qingdao Or Any Port In China

hobby mill drill ZX7045 Drilling and milling machine mill/drill machines

Product Paramenters

The main performance characteristics:

Reinforced type gear, transmission torque large B1 type optional2-speed motor, spindle speed range widely. Application: Widely used in single or batch is machinery manufacturing industry; instrument; building decoration and repair department.

Product main technical specifications:

Specifications	ZX7016	ZX7025	ZX7032	ZX7045
Max. Drilling capacity (mm)	16	25	31.5	45
Max. face mill capacity (mm)	40	63	80	80
Diameter of vertical milling (mm)	10	13	22	28
Diameter of column (mm)	/	/	/	/
Spindle travel (mm)	80	110	130	120
Distance spindle axis to column generating line(mm)	182	240	202	260
Max. Distance spindle nose to table (mm)	360	510	460	475
Spindle taper	MT2	MT3	MT3	MT4
Spindle speeds range (r/min)	320～3300	290～2150	100～2150	95～1600
Spindle speeds series	12	5	12	6
Spindle feeds (mm/r)	/	/	/	/
Dimension of worktable surface (mm)	420×152	555×195	Standard : 730x210 select: 820x240	Standard : 730x210 select: 820x240
Table travel (mm)	230×120	240×140	Standard : 450×170 select: 540x170	Standard : 450×170 select: 540x170
Dimension of base (mm)	/	/	/	/
Overall height (mm)	900	1130	1100	1050
Main motor (W)	550	750 (6P)	Single-phase:1100 Three-phase: 1500	Single-phase:1100 Three-phase: 1500
Coolant motor (W)	/	/	/	/
G.W/N.W(Kg)	100/75	190/160	285/250	318/278
Packing dimension (cm)	65×58×77	87×67×102	97×77×124	97×77×116
